NATWAY FRESH RO UV UF TDS MN ALKALINE

Key Technologies:

1. Reverse Osmosis (RO) Technology:

   • RO Membrane Size: [XX GPD]
   • TDS Reduction: Up to 90-95%
   • Water Flow Rate: [XX L/hr]
   • Recovery Rate: 30-50%
   • Membrane Life: 12-18 months (dependent on water quality)

2. Ultraviolet (UV) Sterilization:

   • UV Lamp: 11W high-efficiency UV lamp
   • Sterilization Capacity: 99.99% bacteria and virus removal
   • Lamp Life: 8000 hours

3. Ultra-Filtration (UF):

   • UF Membrane Pore Size: 0.01 microns
   • Removes: Suspended particles, cysts, and microorganisms

4. TDS Control:

   • TDS Controller: Adjustable TDS to retain essential minerals
   • TDS Level: Adjustable between 50-1500 ppm (based on input water)

5. Mineralization (MN) Cartridge:

   • Mineral Replenishment: Adds essential minerals like calcium and magnesium
   • Output: Improved taste and water quality

6. Alkaline Technology:

   • pH Range: 8.5 - 9.5 (adjustable)
   • Alkaline Filter: Enhances water pH, making it more alkaline for health benefits
   • Added Minerals: Calcium, Potassium, Sodium, etc.

Filtration Stages:

1. Pre-sediment Filter (5 microns)
2. Activated Carbon Filter (Removes chlorine and organic impurities)
3. RO Membrane (Removes dissolved salts, heavy metals)
4. UF Membrane (Provides added filtration against suspended impurities)
5. UV Chamber (Kills bacteria and viruses)
6. Alkaline Mineral Filter (Balances pH and adds healthy minerals)
7. Post Carbon Filter (Enhances taste and odor)

General Specifications:

• Water Storage Tank: 8-12 liters (food-grade plastic)
• Power Consumption: 50-60W
• Operating Input Voltage: 100-300V AC, 50Hz
• Dimensions: [HxWxD - custom dimensions based on design]
• Weight: [XX kg]

Other Features:

• Auto Shut-Off: Saves power by turning off when the tank is full
• Filter Change Indicator: Notifies users to replace filters
• Leakage Protection: Automatic water cutoff for leakage detection

Warranty:

• Machine: 1-year warranty
• Filters and Consumables: No warranty (to be replaced periodically)
