NATWAY PERFECT RO UV UF TDS AMN ALKALIN

NEXCELL PERFECT RO Water Purifier Specifications

Model Name: NEXCELL PERFECT

Key Technologies:

1. Reverse Osmosis (RO) Technology:

   • RO Membrane: 75/100 GPD
   • TDS Reduction Efficiency: Up to 90-95%
   • Water Flow Rate: 10-12 L/hr
   • Recovery Rate: 30-50% (depending on input water quality)
   • Membrane Life: 12-18 months (based on water quality)

2. Ultraviolet (UV) Sterilization:

   • UV Lamp Power: 11W
   • Sterilization Efficiency: 99.99% against bacteria and viruses
   • UV Lamp Life: 8000 hours

3. Ultra Filtration (UF):

   • UF Membrane Pore Size: 0.01 microns
   • Effectiveness: Removes suspended particles, cysts, and microorganisms without altering the taste of water.

4. TDS Controller:

   • TDS Range: Adjustable between 50-1500 ppm (dependent on input water)
   • TDS Control: Allows adjustment to retain essential minerals

5. Alkaline Filter:

   • pH Level: Boosts pH to an optimal level between 8.5-9.5 for healthy, alkaline water
   • Alkaline Benefits: Enhances pH levels and adds essential minerals like calcium, potassium, and magnesium for improved health benefits.

6. Anti-Microbial (AMN) Protection:

   • AMN Technology: Special anti-microbial coating in storage tank and filter housing to prevent bacterial growth.
   • Benefit: Ensures the purified water remains safe and hygienic even during storage.

Filtration Process:

1. Stage 1: Pre-sediment Filter (5 microns) – Removes large particles like dust, rust, and sand.
2. Stage 2: Pre-Carbon Filter – Absorbs chlorine, harmful chemicals, and organic impurities.
3. Stage 3: RO Membrane – Filters out dissolved salts, heavy metals, and chemical impurities.
4. Stage 4: UF Membrane – Provides an additional layer of purification by removing bacteria and cysts.
5. Stage 5: UV Chamber – Kills bacteria and viruses with 99.99% efficiency.
6. Stage 6: Alkaline Mineral Filter – Adjusts the pH level and adds essential minerals like calcium, potassium, and magnesium.
7. Stage 7: Post-Carbon Filter – Polishes water for better taste and odor.

Technical Specifications:

• Storage Capacity: 8-12 liters (food-grade, anti-microbial plastic)
• Purification Capacity: 10-12 liters per hour
• Power Consumption: 50-60W
• UV Power: 11W
• Input Voltage: 100-300V AC, 50Hz
• Dimensions: [H x W x D - customizable]
• Net Weight: [XX kg]
• Body Material: ABS food-grade plastic, anti-microbial finish
• Operating Temperature: 10°C - 40°C

Special Features:

• Auto Shut-Off: Automatically turns off when the tank is full, saving power.
• Filter Change Indicator: Alerts when it's time to replace the filters.
• Leak Detection: Automatic water cutoff to prevent leakage.
• TDS Adjustability: Fine-tune the TDS level for healthier water.
• Anti-Microbial Tank: Keeps stored water safe and free from bacterial growth.

Warranty:

• Product Warranty: 1-year comprehensive warranty on the purifier.
• Filters and Consumables: Periodic replacement required; no warranty.
